Afagobot 4-Channel RC Digital Servo Tester & ESC Consistency Checker – PPM Signal, Analog & Digital Servos (50Hz / 125Hz / 250Hz)

The Afagobot RC Digital Servo Tester is a powerful and precise tool designed for RC car, truck, helicopter, airplane, and drone pilots who demand accurate servo and ESC performance. With the ability to test up to four servos simultaneously, this compact tester is ideal for setup, diagnostics, and consistency checks at the bench or in the field.

Supporting manual, neutral, and automatic modes, the Afagobot servo tester allows you to quickly verify servo centering, smooth movement, and ESC throttle response. It is fully compatible with analog and digital servos, offering selectable signal frequencies of 50Hz, 125Hz, and 250Hz to match your specific RC setup.

The tester delivers an ultra-precise output signal width ranging from 800–2200µs, accurate to 2µs, making it perfect for detecting subtle servo response changes that cheaper testers often miss. The built-in PPM signal test function with display gives you clear, real-time feedback for advanced troubleshooting and tuning.

Whether you’re dialing in a high-performance FPV drone, setting up a scale RC car, or testing helicopter servos before flight, this Afagobot tester is a must-have tool in any RC hobbyist’s toolbox.

🔹 Key Features

• Controls up to 4 servos at the same time
• Works with RC cars, trucks, helicopters, airplanes & drones
• 3 operating modes: Manual / Neutral / Automatic
• Supports analog & digital servos
• Signal frequencies: 50Hz (Analog servos) / 125Hz (Digital servos) / 250Hz (High-speed digital servos)
• Output signal width: 800–2200µs
• High precision: ±2µs accuracy
• PPM signal test function with LCD display
• Ideal for ESC testing and servo consistency checks
• Compact and easy to use

🔹 Technical Specifications

• Channels: 4
• Input Voltage: 4.8V – 6V
• Signal Width: 800–2200µs
• Accuracy: 2µs
• Servo Types: Analog & Digital
• Application: Servo testing, ESC testing, PPM signal diagnostics

🔹 Package Includes

• 1 × Afagobot RC Digital Servo Tester
